XY2100S
Industry scenario SoC with both NB-IoT communication and low-power MCU capabilities
XY2100S is a high-performance SoC based on narrowband IoT communication protocols with highly integrated and low power consumption. It’s designed to meet the needs of a variety of industry applications. XY2100S can be used as the main control MCU, using Cortex-M3 as the application core processor, with a built-in 4KB cache controller. It also has a completely open processor core and independent memory space. The fast wake-up response time and supporting for various low-power policies allows the XY2100S to replace external MCU chips. In addition,XY2100S has ultra-high integration, built-in RF switch and CMOS PA, integrated power management unit and LCD driver. All the designs will reduce the difficulty of customer product development,and greatly reduce the product BOM cost.XY2100S chip has a built-in co-processor, and it supports a variety of communication protocols,such as TCP/UDP, HTTP(s), MQTT, CoAP, etc. XY2100S provides plenty of peripheral interfaces,which are convenient for users to develop, and can be widely used in IoT products such as smartmetering, location tracking, and door magnetic monitoring.
Product Advantage
-
-
High integration, low cost
Integrated PA, filter, Switch, etc.
32K crystal free design
-
Low-power MCU replaces traditional plug-in MCU
Clk frequency ranges: 32Kh~92Mhz,for flexible MCU low power operation
Support 4KB Cache
MCU active mode：[email protected]
-
Storage resources meet the needs of OpenCPU
Built in 4MB Flash
Built in 96KB Retention SRAM
Support external QSPI Flash/PSRAM
-
Rich peripheral resources
GPIO *50
AuxADC：support 10 channels
LCD driver： 8com*20seg；4com*24seg; support screen display
SVD voltage detection
-
Basic Parameter
-
-
Communication protocol
R13, R14, R15
-
Processor
ARM Cortex - M3; 32K~92Mhz
-
Encapsulation
9mm*9mm QFN88
-
Frequency band
Bands 3/5/8/20/28
-
Hardware peripheral
UART/CSP/GPIO /ADC/I2C/SPI/QSPI/LCD etc.
-
Operating temperature
-40°C to +85°C
-
